KBN REBAR delivers rebar shop drawings, bar bending schedules and tonnage estimates that fabricators, contractors and site crews can rely on.
From first-pass shop drawings to fully coordinated BBS, every deliverable is checked against the structural design before it reaches your bender.
Fully dimensioned placement and fabrication drawings for slabs, beams, columns, footings and walls.
Mark-wise BBS with bar shape codes, cut lengths and weights, reconciled against drawing quantities.
Quantity take-off and rebar tonnage estimates from tender drawings, priced by grade and diameter for accurate bidding.
Connection, erection and fabrication drawings for structural steel packages tied to the concrete scope.
Independent checking of consultant or contractor drawings for congestion, cover and code compliance.
Fast turnaround on RFIs, revision tracking and as-built updates through project close-out.
A fixed five-stage workflow keeps every drawing traceable back to the design intent and the fabricator's shop practice.
Structural drawings and specs reviewed; scope and bar schedule format confirmed.
Reinforcement placed in drawing per code, cover and lap requirements.
Shape codes, cutting lengths and weights extracted and cross-checked.
Independent checker reviews clashes, congestion and quantity variance.
Drawings issued for fabrication with RFI support through construction.
"KBN REBAR's schedules matched our bender's output within half a percent on tonnage. That's the difference between a clean pour and a site delay." — Site Engineer, Residential Tower Project, Chennai
